IObserver Class Reference

#include <IObserver.h>

Inheritance diagram for IObserver:

Public Types
enum	{ kDefaultIID = IID_IOBSERVER }

Public Member Functions
virtual void	Update (const ClassID &theChange, ISubject *theSubject, const PMIID &protocol, void *changedBy)=0
virtual void	AutoAttach ()=0
virtual void	AutoDetach ()=0
virtual void	SetAttachIID (PMIID iid)=0
virtual PMIID	GetAttachIID () const =0
virtual void	SetEnabled (bool16 state)=0
virtual bool16	IsEnabled () const =0
virtual void	LazyUpdate (ISubject *theSubject, const PMIID &protocol, const LazyNotificationData *data)=0
Public Member Functions inherited from IPMUnknown
virtual IPMUnknown *	QueryInterface (PMIID interfaceID) const =0
virtual void	AddRef () const =0
virtual void	Release () const =0

Detailed Description

This interface provides a notification mechanism for objects that need to be

informed of changes made to another object. An observer attaches to the subject interface (ISubject) on the object it wants to be notifed of when a change occurs. The observed object can be another boss object, or itself if the observer is interested in changes made to its own interfaces. An object is allowed to have multiple IObserver interfaces as long as each observer has a unique interface ID.

See Also

ISubject for documentation on the two types of notification available, regular notification and lazy notification.

Member Function Documentation

virtual void IObserver::AutoAttach ( )

pure virtual

If the observer knows which subject(s) to attach itself to, it'll do so with this call

Implemented in SelectionHighlightObserver, TranFxUIDialogObserver, StrMutSelectionObserver, CusDtLnkUITreeObserver, IDHAObserver, BscSlDlgTabDialogObserver, CustSEObserver, PnlTrvTreeObserver, PreviewableColorListObserver, CustomHttpLinkUIPlaceButtonObserver, GTTxtEdtStoryObserver, LnkWtchCacheManager, SnipRunGoButtonObserver, PDFVTUIDialogObserver, LnkWtchActiveContextObserver, PnlTrvNodeObserver, PstLstDocObserver, SnipRunPanelWidgetObserver, WatermarkUIDialogObserver, CusDtLnkUITreeNodeObserver, DCLSizListBoxObserver, CustomHttpLinkUIObserver, TableCellObserver, CelPnlEditBoxObserver, WLBCmpListBoxObserver, BscSlDlgDialogObserver, GTTxtEdtNewDeleteStoryObserver, XDocBkUIDialogObserver, GTTxtEdtGoToTextButtonObserver, CusDtLnkDocObserver, WLBCmpEyeballObserver, WLBCmpPenObserver, SwatchesObserver, BscL10NDialogObserver, TxtExpDialogObserver, BscDlgDialogObserver, CusDtLnkUIBrowsDialogObserver, TblAttWidgetObserver, TblBscDialogObserver, CDialogObserver, CdlChtUIWidgetObserver, PreflightCheckBoxObserver, TKIPanelWidgetObserver, CObserver, PicIcoRollOverButtonObserver, WFPDialogObserver, CSelectableDialogObserver, CusCondTxtTreeViewObserver, GraphicStateDefnObserver, ActiveSelectionObserver, and TKITreeWidgetObserver.

virtual void IObserver::AutoDetach ( )

pure virtual

If the observer knows which subject(s) to detach itself from, it'll do so with this call

Implemented in SelectionHighlightObserver, TranFxUIDialogObserver, StrMutSelectionObserver, CusDtLnkUITreeObserver, BscSlDlgTabDialogObserver, IDHAObserver, PnlTrvTreeObserver, CustomHttpLinkUIPlaceButtonObserver, CustSEObserver, PreviewableColorListObserver, GTTxtEdtStoryObserver, LnkWtchCacheManager, SnipRunGoButtonObserver, LnkWtchActiveContextObserver, PDFVTUIDialogObserver, PnlTrvNodeObserver, CusDtLnkUITreeNodeObserver, DCLSizListBoxObserver, PstLstDocObserver, SnipRunPanelWidgetObserver, TableCellObserver, CustomHttpLinkUIObserver, WatermarkUIDialogObserver, CelPnlEditBoxObserver, WLBCmpListBoxObserver, BscSlDlgDialogObserver, GTTxtEdtNewDeleteStoryObserver, GTTxtEdtGoToTextButtonObserver, WLBCmpEyeballObserver, WLBCmpPenObserver, XDocBkUIDialogObserver, CusDtLnkDocObserver, SwatchesObserver, BscL10NDialogObserver, TxtExpDialogObserver, BscDlgDialogObserver, PreflightCheckBoxObserver, TblAttWidgetObserver, TblBscDialogObserver, CdlChtUIWidgetObserver, PicIcoRollOverButtonObserver, CusDtLnkUIBrowsDialogObserver, CSelectableDialogObserver, ActiveSelectionObserver, CObserver, WFPDialogObserver, CDialogObserver, TKIPanelWidgetObserver, CusCondTxtTreeViewObserver, GraphicStateDefnObserver, and TKITreeWidgetObserver.

virtual PMIID IObserver::GetAttachIID ( ) const

pure virtual

Get the interface ID of this observer.

Returns

the interface ID of this observer

Implemented in CObserver.

virtual bool16 IObserver::IsEnabled ( ) const

pure virtual

Returns kTrue if this observer is enabled, kFalse otherwise

Implemented in CObserver.

virtual void IObserver::LazyUpdate ( ISubject *  theSubject, const PMIID &  protocol, const LazyNotificationData *  data  )

pure virtual

Lazy notification of a change in an observed subject; this method is called after the transaction in which the change was performed completes and after undo or redo.

Parameters

theSubject	is the subject that changed
protocol	is the interface of the subject's boss that changed
data	lazy notification data or nil. Observers must be able to handle a call that has nil data. In certain low memory conditions the lazy notification data passed to ISubject::ModelChange may not be passed on to observers. The observer must be able to work without data in which case the observer would usually refresh its entire state by re-examining all objects of interest. See LazyNotificationData for documentation.

See Also

ISubject::AttachObserver(IObserver*, const PMIID&, AttachmentType) to receive lazy notification attach to the subject by calling this method specifying an attachment type of lazy, or, both if you also want regular notification.

IObserver::Update for regular notification

Implemented in LnkWtchActiveContextObserver, CusDtLnkUITreeObserver, PnlTrvTreeObserver, IDHAObserver, LnkWtchCacheManager, CustSEObserver, CusDtLnkDocObserver, CObserver, and CusCondTxtTreeViewObserver.

virtual void IObserver::SetAttachIID ( PMIID  iid )

pure virtual

Set the interface ID of this observer; normally this is IID_IOBSERVER but if there are several observers on a boss they each need to have a different interface ID.

Parameters

iid	is the interface ID of this observer

Implemented in CObserver.

virtual void IObserver::SetEnabled ( bool16  state )

pure virtual

Enable or disable the observer; a disabled observer will not receive an update for a change.

Parameters

state

kTrue to enable, kFalse to disable

Implemented in CObserver.

virtual void IObserver::Update ( const ClassID &  theChange, ISubject *  theSubject, const PMIID &  protocol, void *  changedBy  )

pure virtual

        Regular notification of a change in an observed subject; this method is called immediately after the

        change is made, it is not called on undo or redo.

Parameters

theChange	represents the change to an object, often this is the ClassID of the command that made the change
theSubject	is the subject that changed
protocol	is the interface of the subject's boss that changed
changedBy	is used to pass additional data about the change, often this is a pointer to the command that caused the change

See Also

ISubject::AttachObserver(IObserver*, const PMIID&, AttachmentType) to receive regular notification attach to the subject by calling this method specifying an attachment type of regular, or, both if you also want lazy notification. You can also receive regular notification by attaching to the subject using ISubject::AttachObserver(IObserver*,const PMIID&,const PMIID&).

IObserver::LazyUpdate for lazy notification

Implemented in SelectionHighlightObserver, TranFxUIDialogObserver, CusDtLnkUITreeObserver, PnlTrvTreeObserver, PstLstDocObserver, CustomHttpLinkUIPlaceButtonObserver, DCLSizListBoxObserver, PDFVTUIDialogObserver, PnlTrvNodeObserver, CusDtLnkUITreeNodeObserver, LnkWtchActiveContextObserver, PreviewableColorListObserver, GTTxtEdtStoryObserver, SnipRunPanelWidgetObserver, CustomHttpLinkUIObserver, LnkWtchCacheManager, WLBCmpListBoxObserver, SnipRunGoButtonObserver, WatermarkUIDialogObserver, BscSlDlgDialogObserver, IDHAObserver, XDocBkUIDialogObserver, BscSlDlgTabDialogObserver, WLBCmpEyeballObserver, WLBCmpPenObserver, BscL10NDialogObserver, CustSEObserver, TxtExpDialogObserver, BscDlgDialogObserver, CusDtLnkUIBrowsDialogObserver, GTTxtEdtNewDeleteStoryObserver, TblBscDialogObserver, GTTxtEdtGoToTextButtonObserver, PreflightCheckBoxObserver, CusDtLnkDocObserver, PicIcoRollOverButtonObserver, WFPDialogObserver, CdlChtUIWidgetObserver, ActiveSelectionObserver, TKIPanelWidgetObserver, TblAttWidgetObserver, TableCellObserver, CelPnlEditBoxObserver, SwatchesObserver, CusCondTxtTreeViewObserver, CDialogObserver, CSelectableDialogObserver, and TKITreeWidgetObserver.
